| Thread Standard | Metric | Cutting Edge Material | HSS |
| Thread Size | M4 × 0.7 | Tool Type | High Performance Tap |
| Thread Diameter Size (TDZ) | M4 | Applicable Material | | Hard Materials | |
| Thread Pitch (TP) | 0.7 mm | Connection Diameter Machine Side (DCONMS) | 4.26 mm |
| Thread Tolerance Class (TCTR) | D4 | Thread Cutting Part Length (THL) | 3/4″ |
| Usable Length (LU) | 19 mm | End Shape | Spiral Point |
| Overall Length (OAL) | 2-1/8″ | Style | Plug |
| Chamfer | 4P-4.5P | Measurement Type | Metric |
| Coating | Black Oxide | Series/List # | 289 |
| Flute Count (NOF) | 3 |
Product Features
| Remarks | •Spiral Point Plug Style •For tapping hardened steel •Best Application: 4140, 4340, H13, D2 and 1055 up to 35HRC | Country of Origin | Mexico |
Shipping Info
Package Length
3.10000
Package Width
.30000
Package Height
.30000
Package Weight
0.014
